ST38 HiArc

Performance LED Urban Lights Nema Socket Zhaga Socket With Glass Dark Sky Approved Plug and Play Sensor

HiArc LED Post top brings architectural style to area and site and pedestrian scale applications, the design brings a desired organic look into the urban environment. Professional optic provides an excellent effect, managing glare while providing high levels of visibility.

  • Contemporary, architectural design.
  • Smooth housing without any screws exposed.
  • Lumen packages ranging from 5200 - 13000lm
  • 100-277V 50/60Hz.
  • Professional LED Optical technology
  • IP66 IK08 Rated, 3G Rated.
  • φ60mm mount available.
  • Protection Class I or Class II.
  • Integrated photocell, NEMA Socket, ZHAGA base, plug-and-play motion & PIR control solutions.
* AGC products are designed for global market. Please contact our sales team for certification details.
* Products information is for reference only. Some options may not be available for each configuration. Please contact us for further details.
ST38 P1
ST38 P2
ST38 P3
ST38 P4
Series CodeST38
Power40W, 60W, 75W, 100W
Efficacy130lm/W
Input Voltage100-240 VAC, 50 / 60 Hz
Power Factor>0.92
Surge Protection6kV line-line, 10kV line-earth
ControlDimmable, DALI, Microwave Sensor, PIR Sensor, Zhaga Socket, Photocell, Non-Dimmable
IP RatingIP66
IK RatingIK08
CCT3000K, 4000K, 5000K
CRI(Ra)70, 80
Operating Temperature-30°C to + 50°C
Mounting OptionPost Top
Warranty5 Years
