UST03 Lotus

Specification LED Urban Lights Invisible Screw Design Dark Sky Approved Smooth Design Parking Lot With Glass

Lotus LED post top -the IF Award 2020 Winner, brings architectural style to area and site and pedestrian scale applications. Its professional optic provides a high level of visibility and manages the glare well.

  • Contemporary, architectural design, elegant appearance.
  • Smooth housing without any screws exposed.
  • 40W 60W 75W 100W with 120lm/W.
  • 7 optics available.
  • φ60mm & φ76mm mount kit available.
  • Post top installation or wall mounting.
* AGC products are designed for global market. Please contact our sales team for certification details.
* Products information is for reference only. Some options may not be available for each configuration. Please contact us for further details.
UST03 post top 01
UST03 post top 02
UST03 post top 03
UST03 post top 04
Series CodeUST03
Power40W, 60W, 75W, 100W
Efficacy120lm/W
Input Voltage100-240 VAC, 100-277VAC, 50 / 60 Hz
Power Factor>0.90
Surge Protection6kV line-line, 10kV line-earth
Control1-10V, DALI, Dimmable
IP RatingIP66
IK RatingIK08
CCT5000K, 4000K
CRI(Ra)80, 70
Operating Temperature-30°C to + 50°C
Mounting OptionPost Top
Warranty5 Years
