HiFlex

The product has been delisted on the website, please contact our sales team.

Multiple wattage option from 200W to 600W. 200W per module as expected, helps easy assembly and quick connection of each parts. Universal angle adjustment-horizontally and vertically, Easy way to adjust the light angle and create diversity of lighting environment. Multiple optics option from 10° 15°, 30° and 20°*60°.  Add visor makes excellent light pollution control. Support position the driver on the bottom of the pole as well, maintenance friendly. Wide applications for large sports, large plazas, large docking space, etc.

  • Modular design from 200W to 600W.
  • Efficiency up to 135lm/W, more energy saving.
  • Provided with 10KV Build-in Surge Protection Devices.
  • Electrophoresis and powder coating with strong anti-corrosion.
  • Multiple optics option from 10° 15° to 30° to offer excellent light pollution control.
  • This convenient and humanized design enable it fit for different requests in outdoor lighting applications.
  • Vertically angle adjustment, easy way to adjust the light angle and create diversity of lighting environment.
* AGC products are designed for global market. Please contact our sales team for certification details.
* Products information is for reference only. Some options may not be available for each configuration. Please contact us for further details.

Standard  Version:

Model No. FL13-200 FL13-400 FL13-600
Power Consumption 200±10W 400±12W 600±18W
Luminous Flux(±5%) 27000(±5%)lm 54000(±5%)lm 81000(±5%)lm
Efficacy (5000K, Ra70) 135(±5%) LM/W
Correlated Color Temperature 5000K (3000K, 4000K optional)
Color Rendering Index Ra70 (Ra80, Ra90 optional)
Beam Angle F06001,F06002,F06003, F06004, F06005, F06006
Input Voltage 100-240 VAC / 100-277 VAC
Power Factor >0.92
Frequency 50 / 60 Hz
Surge Protection 6kV line-line, 10kV line-earth
Driver Type Constant Current (CC)
Product Dimension 321×316×118mm(12.64"×12.44"×4.65") 419×340×222mm (16.5"×13.39"×8.74") 529×340×226mm(20.83"×13.39"×8.9")
Luminaire Net Weight 4.1±0.3kg (9.04±0.66Lbs) 9.4±0.3kg (20.72±0.66Lbs) 15.3±0.5kg (33.73±1.1Lbs)
Export Carton Size 360×160×375mm (14.17"×6.3"×14.76") 478×270×390mm(18.82"×10.63"×15.35") 598×280×400mm(23.54"×11.02"×15.75")
Gross Weight  4.7±0.3kg (10.36±0.66Lbs) 10.6±0.3kg (23.37±0.66Lbs) 16.8±0.5kg (37.04±1.1Lbs)
Finish Powder Coating
Fixture Color  Silver
IP Rating IP65
Mounting Option Bracket Mounting
OperatingTemperature -30°C to + 40°C (-22°F to 104°F)
Life Time >50,000Hrs (Ta=30°C@L70)
Warranty 5 Years
Dimmable  Dimmable and Non-dimmable
Intelligent Control DALI Control
Accessory Visor
Plug - EU/US Standard Plug
Series CodeFL13
Power200W/400W/600WW
Efficacy135LM/Wlm/W
IP RatingIPIP65
