SP01 Index

SP01 Index

Index is modular and designed to easily make DIY, updating, and maintenance. CRI 90+ and TLCI up to 90, flicker-free operation solution for HDTV broadcasting is optional. Its vertical installation offers a far projection distance, making it especially well-suited for large-scale events.

  • Each module is 400W. Easy to assemble makes it possible to DIY floodlights for projects.
  • Special powder coating to ensure excellent anti-corrosion performance.
  • Professional asymmetrical optics with adjustable brackets can minimize back-lighting, up-lighting, and spill-lighting effectively.
  • Flexible installations: driver fixed on the fixture, on the pole directly, or installed into the electrical cabinet.

Applications: Precise optics and electrical characteristics make it perfect for outdoor high mast and HDTV broadcasting applications. A special powder coating process makes it to be used in harsh environments, such as stadiums, soccer fields, ski resorts, golf courses, docks, stations, and other high pole area etc.

* AGC products are designed for global market. Please contact our sales team for certification details.
* Products information is for reference only. Some options may not be available for each configuration. Please contact us for further details.
SP01LED Sports Light 01
SP01LED Sports Light 02
SP01LED Sports Light 03
SP01LED Sports Light 04
SP01 aiming device for precise control 5
Series CodeSP01
Power400W, 800W, 1200W, 1600W, 1800W
Efficacy140lm/W
Input Voltage220-240VAC, 200-420VAC, 50 / 60 Hz
Power Factor>0.92, >0.95
Surge Protection10kV line-line, 20kV line-earth
ControlDALI, DMX
IP RatingIP66
IK RatingIK08
CCT3000K, 4000K, 5700K
CRI(Ra)70, 80, 90
Operating Temperature-30°C to + 50°C
Mounting OptionBracket Mounting
Warranty5 Years
